The main characteristics of the three-phase AC network are its voltage class, frequency, and method of neutral grounding. Speaking of voltage, there are two different voltages (the designations may depend on the country):✅ Rated voltage (let it be Ur);✅ Maximum continuous operating voltage (let it be Umcov). Both voltages are the effective value of the
One of the ways to reduce lightning outages of overhead lines (OHL) is to place surge arresters (SA) on problematic sections of the line. However, there is always a risk of damage to the SA itself which creates a new problem. For example, damage can happen for one of the following reasons:✅ Lightning can transfer
Let us continue the series of green posts. There is such a thing as “temporary overvoltages” (TOV), and one example of such processes is ferroresonance. Ferroresonance, like ordinary resonance, occurs in circuits containing capacitances and inductances. However, unlike resonance, with ferroresonance, it is important that the inductance does not remain constant, but changes depending on
We know that the screen’s cross-bonding is an effective way to deal with induced currents and losses in the screens of 6-500 kV cable lines (CL). The use of cross-bonding allows not only to save on losses (dozens of thousands of euros annually), but also to increase the permissible core current of the cable line,
For lines with single-core cables, there is a problem of selecting the optimal screens’ bonding type. It is especially relevant for 110-500 kV lines, where grounding of screens on both sides is almost prohibited, and 99% of lines have either grounding of screens on one side or cross-bonding of screens. In both cases, it is
Dear colleagues, let me please start a series of “green posts” on electromagnetic transients and protection against them. In general, I have to admit that there are too many experts in this area in the world, and it seems to me sometimes, they are ready to fight brutally for their right to exist under this
Lightning processes are statistical processes. It is hardly possible to study such processes by considering a lightning strike to the line with specific parameters (current, front) or by considering a specific lightning wave coming from the line to the switchgear. To calculate the probability, I normally use ATP/EMTP, which has been changed for the convenience
To protect the transformer from lightning surges, the metal-oxide arrester (MOA) is often placed directly at its bushings, at a distance of no more than 2-3 m. This creates an impression that the transformer will be fine. In fact, this is a false impression, and the effect on the windings depends not only on the
All the experience allows the author to state that the global metal-oxide surge arrester (MOA) industry is in dire need of simple MOA application methods, but, instead it, is developing endless editions of IEC 60099, adding details to an already complex document that contains dozens of MOA characteristics. At the same time, IEC 60099 does not divide
In the energy industry, many processes can not only be calculated on models, but also measured in an operating network. Measurements are important because they allow us to verify the models and, if necessary, adjust them. One of the areas where measurements in the network are practically impossible is impulse processes (lightning and switching). Therefore,
